KEY FEATURES
- Positive Power Tolerance Modules.
- Highly Classified A-Grade Solar Cells for Lesser Degradation and High Energy.
- Micro Crack Free Panels-100% EL Tested Before and After Lamination.
- High Conversion Efficiency based on Leading Innovative Photo Voltaic Technologies.
- PID Free Modules with Long Term Reliability.
- Anti-Reflective Coating Glass Available.
- Advance IP67/IP68 Junction Box for long-term weather endurance.
- RFID Tag Available.
- Sustain Heavy Wind and Snow Loads (2400Pa and 5400Pa).
- Excellent Performance in Low Light.
- Salt Mist, Ammonia, Blowing Sand and Hail Resistant.
- Ideal for Off-Grid as well as On-Grid Applications.
- IP67 rated MC4 Compatible Connectors.
- EVA Encapsulation and Anti Reflection Coating for better Module Protection
Technical Info Nominal Maximum Power (Pm) |
390Watts/24V |
Open Circuit Voltage (Voc) | 49.50V |
Short Circuit Current (Isc) | 9.90A |
Voltage at Maximum Power (Vmp) | 41.7V |
Current at Maximum Power (Imp) | 9.36A |
Maximum System Voltage | 1500V |
General Info
Length x Width x Thickness (LxWxT)
1970x990x35 mm
Mounting Holes Pitch (X)
978/1500 mm
Mounting Holes Pitch (Y)
946
Solar Cells per Module (Units) / Arrangement
72 / (12 x 6)
Solar Cell Type
Mono Crystalline PERC
Front Cover (Material / Thickness)*
Tempered & Low Iron Glass / 3.2mm
Encapsulate*
Ethylene Vinyl Acetate
Frame Material*
Anodized Aluminum Alloy
Junction Box*
IP67/IP68 Enclosure with Bypass Diodes
